Report Offset Values

Up

Back



Text:

Manual Step

Basic Text

User Prompt

In-Line Text



Reports:

Report Header

Units of Meas.

Ordered

Concise

Control Center

Configuration



Features:

Print Tags

SPC Tags

Report Offset





Site Map



helmel.com

Introduction


Ctrl + y GeoPlus→Apply Report Offset
Keyboard Main Menu Toolbar

The Report Offset Tool is used to apply a reference value to a reported attribute on any feature. One example is the rotation of an angle to match the drawing. This allows the printed inspection report to match the drawing. Using an example of a 2D XY Circle, we will apply an offset to the angle.

ID XY Circle [16 pts]

Cartesian Format



Polar Format

ID = 0.5000"   ID = 0.5000"
X = 4.3300"   Pol-R = 4.9999"
Y = 2.5000"   Angle = 30.0007°

Here we show the Cartesian and Polar formats for reference. The angle of 30.0007° is referenced off the x-axis going counter clockwise. The drawing references the angle off the y-axis and has a nominal value of 60.0°. To make a correction to the reported value, we can add a nominal offset value to the reported angle.

Report Offset Tool

As shown in the Report Offset Tool, we entered a –90 in the Pol Angle: control. The result to the reported angle is shown to the right.

ID XY Circle [16 pts]

Before



After

ID = 0.5000"   ID = 0.5000"
Pol-R = 4.9999"   Pol-R = 4.9999"
Angle = 30.0007°   Angle = -59.9993°

The Report Offset can be applied to any feature and any reported position. It is carried forward to inspection runs.
